Kompaktní distribuční bloky

Connections	7
Height (A)	75 mm
Input A: wire cross-section stranded, max.	35 mm²
Input A: wire cross-section stranded, min.	10 mm²
Input A: wire cross-section with wire-end ferrules, max.	35 mm²
Input A: wire cross-section with wire-end ferrules, min.	10 mm²
Length (B)	85 mm
Nominal insulation voltage	600 V
Number of inputs A	1
Number of outputs A	6
Output A: wire cross-section stranded with wire-end ferrules, max.	16 mm²
Output A: wire cross-section stranded with wire-end ferrules, min.	2,5 mm²
Output A: wire cross-section stranded, max.	16 mm²
Output A: wire cross-section stranded, min.	2,5 mm²
Screw type	Galvanized steel screws
Short-circuit current resistance ICW over 1s	4,4 kA
Short-circuit current resistance IPK (peak value)	30 kA
Trieda krytia	IP20
Width (C)	48 mm

Connections

Height (A)

75 mm

Input A: wire cross-section stranded, max.

35 mm²

Input A: wire cross-section stranded, min.

10 mm²

Input A: wire cross-section with wire-end ferrules, max.

35 mm²

Input A: wire cross-section with wire-end ferrules, min.

10 mm²

Length (B)

85 mm

Nominal insulation voltage

600 V

Number of inputs A

Number of outputs A

Output A: wire cross-section stranded with wire-end ferrules, max.

16 mm²

Output A: wire cross-section stranded with wire-end ferrules, min.

2,5 mm²

Output A: wire cross-section stranded, max.

16 mm²

Output A: wire cross-section stranded, min.

2,5 mm²

Screw type

Galvanized steel screws

Short-circuit current resistance ICW over 1s

4,4 kA

Short-circuit current resistance IPK (peak value)

30 kA

Trieda krytia

IP20

Width (C)

48 mm

Objednávacie číslo	Connections	Height (A)	Input A: wire cross-section stranded, max.	Input A: wire cross-section stranded, min.	Input A: wire cross-section with wire-end ferrules, max.	Input A: wire cross-section with wire-end ferrules, min.	Input B: wire cross-section stranded with wire-end ferrules, max.	Input B: wire cross-section stranded, max.	Input B: wire cross-section stranded, min.	Input B: wire cross-section, stranded with wire-end ferrules, min.	Length (B)	Number of inputs B	Number of outputs A	Number of outputs B	Number of outputs C	Output A: wire cross-section stranded with wire-end ferrules, max.	Output A: wire cross-section stranded with wire-end ferrules, min.	Output A: wire cross-section stranded, max.	Output A: wire cross-section stranded, min.	Output B: wire cross-section stranded with wire-end ferrules, max.	Output B: wire cross-section stranded with wire-end ferrules, min.	Output B: wire cross-section stranded, max.	Output B: wire cross-section stranded, min.	Output C: wire cross-section stranded with wire-end ferrules, max.	Output C: wire cross-section stranded with wire-end ferrules, min.	Output C: wire cross-section stranded, max.	Output C: wire cross-section stranded, min.	Short-circuit current resistance ICW over 1s	Short-circuit current resistance IPK (peak value)	Width (C)
3-pólový kompaktný distribucný blok - RPT 125 Položka: RPT3000 Skopírované	7	75 mm	35 mm²	10 mm²	35 mm²	10 mm²					85 mm		6			16 mm²	2,5 mm²	16 mm²	2,5 mm²									4,4 kA	30 kA	48 mm
3-pólový kompaktný distribucný blok - RPT 160 Položka: RPT3005 Skopírované	7	75 mm	70 mm²	10 mm²	50 mm²	10 mm²					85 mm		6			16 mm²	2,5 mm²	16 mm²	2,5 mm²									11 kA	30 kA	48 mm
Unipolárny distribučný blok - RPU 80-6 S Položka: RPU2995 Skopírované	7	66 mm	16 mm²	6 mm²	16 mm²	6 mm²					30 mm		2	4		16 mm²	2,5 mm²	16 mm²	2,5 mm²	6 mm²	2,5 mm²	6 mm²	2,5 mm²					3 kA	22 kA	46 mm
Položka: RPU3005 Skopírované	10	75 mm	70 mm²	10 mm²	50 mm²	10 mm²	16 mm²	16 mm²	6 mm²	6 mm²	40 mm	1	8			16 mm²	2,5 mm²	16 mm²	2,5 mm²									11 kA	30 kA	48 mm
Unipolárny distribucný blok - RPU 250-11 Položka: RPU3010 Skopírované	12	96 mm	120 mm²	35 mm²	95 mm²	35 mm²					47 mm		2	5	4	25 mm²	6 mm²	35 mm²	6 mm²	16 mm²	2,5 mm²	16 mm²	2,5 mm²	10 mm²	2,5 mm²	10 mm²	2,5 mm²	21 kA	51 kA	50 mm
Unipolárny distribucný blok 400 A - RPU 400-11 Položka: RPU3015 Skopírované	12	96 mm	185 mm²	95 mm²	120 mm²	95 mm²					47 mm		2	5	4	25 mm²	6 mm²	35 mm²	6 mm²	16 mm²	2,5 mm²	16 mm²	2,5 mm²	10 mm²	2,5 mm²	10 mm²	2,5 mm²	21 kA	51 kA	50 mm
